Advantages:
-Good chemical resistance and abrasion resistance.
-Improve the extrusion resistance of the seal, thereby increasing the service life of the seal.
Importane Notes:
- The seal can not be used alone, must be used in conjunction with the piston rod seal
- When system pressure is high, PA material is recommended.
- All the back-up rings are divided into integral and open two forms.
| ITM | ID | OD | H |
| JSBRT | 25 | 35 | 2 |
| JSBRT | 30 | 40 | 2 |
| JSBRT | 30 | 40 | 3 |
| JSBRT | 30 | 43 | 3 |
| JSBRT | 32 | 42 | 2 |
| JSBRT | 32 | 48 | 3 |
| JSBRT | 35 | 45 | 2 |
| JSBRT | 35 | 45 | 3 |
| JSBRT | 40 | 50 | 2 |
| JSBRT | 40 | 50 | 3 |
| JSBRT | 40 | 55 | 3 |
| JSBRT | 45 | 55 | 2 |
| JSBRT | 45 | 55 | 3 |
| JSBRT | 45 | 60 | 3 |
| JSBRT | 50 | 60 | 2 |
| JSBRT | 50 | 60 | 3 |
| JSBRT | 50 | 63 | 3 |
| JSBRT | 50 | 65 | 2 |
| JSBRT | 50 | 65 | 3 |
| JSBRT | 50 | 70 | 2 |
| JSBRT | 55 | 65 | 2 |
| JSBRT | 55 | 68 | 3 |
| JSBRT | 55 | 70 | 3 |
| JSBRT | 60 | 70 | 2 |
| JSBRT | 60 | 70 | 3 |
| JSBRT | 60 | 73 | 3 |
| JSBRT | 60 | 75 | 3 |
| JSBRT | 65 | 78 | 3 |
| JSBRT | 65 | 80 | 3 |
| JSBRT | 70 | 80 | 2 |
| JSBRT | 70 | 80 | 3 |
| JSBRT | 70 | 83 | 3 |
| JSBRT | 70 | 85 | 2 |
| JSBRT | 70 | 85 | 3 |
| JSBRT | 75 | 88 | 3 |
| JSBRT | 75 | 88 | 4 |
| JSBRT | 75 | 90 | 3 |
| JSBRT | 75 | 95 | 3 |
| JSBRT | 80 | 93 | 3 |
| JSBRT | 80 | 95 | 2 |
| JSBRT | 80 | 95 | 3 |
| JSBRT | 85 | 100 | 2 |
| JSBRT | 85 | 100 | 3 |
| JSBRT | 85 | 100 | 4 |
| JSBRT | 90 | 105 | 2 |
| JSBRT | 90 | 105 | 3 |
| JSBRT | 90 | 110 | 3 |
| JSBRT | 95 | 110 | 2 |
| JSBRT | 95 | 110 | 3 |
| JSBRT | 95 | 115 | 3 |
| JSBRT | 100 | 115 | 2 |
| JSBRT | 100 | 115 | 3 |
| JSBRT | 100 | 120 | 3 |
| JSBRT | 105 | 120 | 2 |
| JSBRT | 105 | 120 | 3 |
| JSBRT | 110 | 125 | 2 |
| JSBRT | 110 | 125 | 3 |
| JSBRT | 110 | 130 | 3 |
| JSBRT | 115 | 130 | 2 |
| JSBRT | 115 | 130 | 3 |
| JSBRT | 120 | 135 | 2 |
| JSBRT | 125 | 140 | 2 |
| JSBRT | 125 | 140 | 3 |
| JSBRT | 130 | 145 | 2 |
| JSBRT | 145 | 160 | 2 |
What are JSPSEAL Hydraulic Seal made from?
Hydraulic seals can be made from a variety of materials such as polyurethane, rubber or PTFE ect. The type of material is determined by the specific operating conditions or limits due to seal type, pressure, fluid chemical compatibility, speed, surface roguhness, Radial load, Hydraulic shock, or temperature.
Material Characteristics
| Material | Temperature | Media | Velocity | Pressure(MPa) |
| NBR | -45°C to +140°C | Mineral oil baed, hydraulic fluids,biological degradable oils water | 0.5 | 25 |
| FKM | -20°C to +200°C | Mineral oil baed | 0.5 | 25 |
| PU | -30°C to +100°C | Mineral oil baed, hydraulic fluids | 0.8 | 35 |
| TPE | -40°C to +110°C | Mineral oil baed | 0.8 | |
| POM | -45°C to +120°C | Mineral oil baed | 0.8 | |
| PA | -45°C to +120°C | Mineral oil baed | 1.0 | |
| PTFE | -55°C to +200°C | Mineral oil baed,biological degradable oils water | 15 | 40 |
| PHENOLIC RESIN COTTON FABRIC | -50°C to +120°C | Mineral oil baed,biological degradable oils water | 1.0 |
